SAF-110 Double Seal Cartridge Mechanical Seal for Screen
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Detailed Description
Operating Limits:
TEMPERATURE: 180 C°
PRESSURE LIMITS Process pressure: 20 bar
Seal water pressure: 15 bar
SPEED LIMITS：30m/s
Material:
seal face: SIC/SIC(product side), SIC/Carbon(atmosphere side)
O ring: EPDM/Viton
Spring: 316SS
Metal part: 304SS/316SS/2205 duplex stainless steel
Description:
SAF is a double acting seal, which is especially suitable for pumps, screens, knotters, sorters and pulpers in heavy processing industry, including liquids containing solid particles and impurities. The seal design can be multicomponent or cartridge, depending on the application. Dimensions range from 0.787 inches to 17.716 inches / 20 mm to 450 mm.
